Security Door Electromagnetic Lock 600Lbs*2 Holding Force With LED Lock Signal

Product Details:

Place of Origin:	Shenzhen China
Brand Name:	Vians
Certification:	CE/ROHS/FCC/MA/UL
Model Number:	VI-280BS

Payment & Shipping Terms:

Minimum Order Quantity:	10 pcs
Price:	negotiation
Packaging Details:	10PCS/Carton
Delivery Time:	Usually 7 days after payment confirmed.
Payment Terms:	T/T or
Supply Ability:	3,000pcs per month

Contact Now

Detailed Product Description

Holding Force:	280kgs2 (600lbs2)	Coil Material:	Aluminium Alloy
Lock Size:	5004726mm	Signal:	Lock Signal Output
Input Voltage:	12V Or 24V Optional	Security Type:	Power Off To Open
Highlight:	electromagnetic door lock , electric mag locks

600Lbs*2 Holding force Security Door Electric Magnetic Lock Double Door with LED Lock Signal

Introduction of Mag Locks

The design of electromagnetic lock is the same as the electromagnet. By using the principle of electromagnetic, when current passes through the silicon steel sheet, magnetic locks will produce powerful suction, thereby help to tightly attract iron plate. Even small current will produce huge magnetic, which can effectively lock the door.

Specification

Product Parameter	Parameter Description
Size	500L47W26H(mm)
Armature Plate Dimension	180L38W11H(mm)
Holding Force	280kgs2/600lbs2
Input Voltage	12V or 24V optional
Current	12V/480mA 2 or 24V/240mA2
Bracket Shapes	L ,ZL ,U , F bracket
Surface Temp	≤+20℃
Operating Temp	-10~+55℃(14-131F)
Humidity	0~90%(non-condensing)
Housing finish	Aluminum alloy
Lock Finish	Zinc
Security Type	Power off to open
Weight	4 kg

Features of this product

1. Powerful static linear holding force

2. Adjustable voltage 12V or 24V .
3. Anti-wear manufacturing materials .

4. Built-in reverse current protection device (MOV)

5. High-strength aluminum alloy shell

6. Superior quality and reliable performance.

Installation of mag locks

Security Door Electromagnetic Lock 600Lbs*2 Holding Force With LED Lock Signal 0

Factroy Informations

Vians electric lock factory has been specialized in producing electric locks for about 10 years, with full experience and professional in high-quality material puchasing , efficient production management , quality control and so on. Besides, we are trying our best to provide a better purchase experience for all of our customers. Every year, we are trying to attend many exhibitions , and also many customers visit our factory for a potential chance to start a new business or try to firgure out a deeper way to coorperate.We would like to cooperate with companies and people from all over the world, with our high-quality electric locks and professional hard work.
Security Door Electromagnetic Lock 600Lbs*2 Holding Force With LED Lock Signal 1
